Nidec Servo Drive

Current loop control cycle: 62.5µs, speed loop control cycle: 125µs, enabling rapid system response suitable for high-speed, high-dynamic applications.

Supports a maximum pulse command frequency of 4MHz, meeting the demands of high-precision positioning and high-speed motion control.

Instantaneous maximum output torque of the servo motor can reach 350% of the rated value, meeting the requirements for high-load start-stop, acceleration, and deceleration in short-term operations.

Supports 23-bit absolute encoder, with a resolution equivalent to 0.15 arcseconds, ensuring high-precision positioning and smooth low-speed operation.

Features a simple wiring design and supports one-touch parameter auto-tuning, significantly reducing commissioning complexity.

Encoder battery replacement is convenient and reliable, ensuring long-term stable system operation.

Equipped with intelligent tuning function, enabling automatic parameter tuning based on load or quick deployment without tuning. Supports offline automatic parameter tuning, improving system integration efficiency.

Incorporates a complete system protection mechanism, including DC bus overvoltage/undervoltage, output line abnormalities, drive overload, braking overload, voltage dips (brownouts), and frequent power-on protection, ensuring stable operation under complex working conditions.

Offers bus-type drive options in the same series: MH72 (EtherCAT bus version) and MH73 (CANopen bus version), meeting the demands of networked, multi-axis coordinated control.

The HDE series servo motors operate at 200V, with a power range of 400W to 2kW. They feature high dynamic response, high torque output, and multiple encoder options. Designed for different load characteristics and duty cycles, the series offers low, medium, and high inertia motor models to meet the precise control needs of various industrial applications

Provides three motor types: low, medium, and high inertia, compatible with pulse-duty and continuous-duty load requirements, meeting the dynamic characteristics of different mechanical structures.

Peak torque can reach 350% of the rated value, offering excellent overload capacity suitable for applications with frequent start-stop, rapid acceleration, and deceleration.

Offers electromagnetic and photoelectric encoder options, with resolutions up to 23 bits, ensuring reliability, anti-interference capability, and precision in various environments.

Particularly suitable for industries such as winding machines, textile machinery, woodworking machinery, and robotic arms, which require high motion control precision, response speed, and reliability.

The combination of the MH71 drive and HDE servo motor provides a complete servo system solution, featuring fast response, high precision, high reliability, and ease of commissioning. It is widely applicable to various automation equipment, helping users enhance equipment performance and reduce overall operating costs.
